MSS SERIES SMALL SINGLE SHAFT SHREDDER

The Affordable Waste Shredding Solution For Your Business!

Makabale's MSS series industrial waste shredder is an economical single shaft shredder. Its robust construction and small footprint make it an ideal shredding solution for small-scale businesses with small volume shredding needs. The MSS shredder features a long, rotating cutting shaft with sharp blades that can easily shred a variety of materials in a single pass, such as cardboard, paper, plastics, fabric, wood, rubber, electronics, and other materials, and the replaceable screen equipped under the rotating shaft provides you consistent shredded particles.

This easy-to-operate small industrial shredder has a user-friendly control panel, and is designed to be energy efficient, with low noise and vibration levels, and low maintenance. The special rotating cutters are reversible, and can be rotated 4 times, reducing your operation cost. The MSS one shaft shredder comes in two model sizes, both of which can be used either stand alone or as a pre-shredder to connect with conveyors and granulators to get smaller particles as per need.

Download Brochure Request A Quote

Features & Benefits Of The MSS Series Small Single Shaft Shredder:

Hydraulic feeding pusher for efficiently pushing and holding the material to be shredded by the cutters
Heavy-duty rotating cutters are reversible and replaceable, reducing operation cost
Replaceable screen for providing consistent shredded particles and is available in different sizes
PLC control allowing for precise control and automation of the machine, increasing efficiency, reliability and accuracy
Automatic reverse sensing protection to safeguard the machine from overload and jamming
User-friendly control panel for easy operation
Large loading hopper suits bulky material feeding
Easy to maintain, low noise operation
Compact design allows for flexible installation
Cost effective solution
Infeed conveyor and discharge conveyor are for option

Main Feature Details

HYDRAULIC FEEDING PUSHER

For pushing and holding the material to be shredded efficiently by the cutters.

HEAVY-DUTY ROTATING CUTTERS

Are reversible and replaceable, reducing operation cost.

REPLACEABLE SCREEN

For providing consistent shredded particles and is available in different sizes.

PLC CONTROL

Allowing for precise control and automation of the machine, increasing efficiency, reliability and accuracy.

The MSS Series Small Single Shaft Shredder Machine Can Shred:

Plastics

Paper & Cardboard

Wood & Biomass

E-waste & Electronics

Textile & Fabrics

Medical Waste

Urban Waste

Soft Metals

The Right Economical Small Single Shaft Shredder For The Job!

Makabale offers 2 models of MSS Series Small Sized Single Shaft Shredder for sale. These shredders are built for a variety of waste material types and industries. Choose from the models or contact us for an industrial waste shredder to meet your unique shredding requirements.

Model	Motor Power	Rotor Diameter	Rotor Speed	Cutting Chamber	Throughput (approx.)
MSS250	15kW (20hp)	220mm (8.7")	83rpm	690mm x 500mm (27" x 20")	150-250kg/h (330-550lbs/h)
MSS260	18.5kW (25hp)	220mm (8.7")	83rpm	790mm x 600mm (31" x 24")	200-300kg/h (440-660lbs/h)
